Features：Machine with advanced technology, beautiful appearance, reasonable structure, stable performance, precise operation, efficient and durable, easy to operate, energy saving and other diversified quality characteristics. Set of measuring, bag m
Application:
Suitable for different kinds of materials like sugar, coffee granule, coffee powder, liquid etc.
Technical parameters:
|
Type |
SYX-420-4K |
|
Bag length |
40-200mm(L) |
|
Bag width |
15-70mm(W) |
|
Max width of roll film |
420mm |
|
Packing speed |
30-50bags/min/lane |
|
Air pressure |
1.5m³/min 6KG |
|
Power voltage |
220V |
|
Power |
3.5KW |
|
Dimension |
(L)1100mm×(W)990mm×(H)2100mm |
|
Machine weight |
500Kg |
Technical characteristics:
1. Machine with advanced technology, beautiful appearance, reasonable structure, stable performance, precise operation, efficient and durable, easy to operate, energy saving and other diversified quality characteristics. Set of measuring, bag making, filling, sealing, cutting, testing, coding, counting, transport and other processes in a fully automatic multi-functional packaging machine.
2. Machine manually using man-machine interface, automatic detection and alarm system program, application imports PLC, cylinder, optical, touch screen, temperature controller, frequency converter, relays, servo motor, high quality power supply circuit.
3. famous branch Servo motor for pulling film system
4. PID temp. controller within 1 degree
