Type |
SYX6132TY |
|
Dimension of sliding table |
3200x375 mm |
|
Gross cut capacity |
3200 mm |
|
Width of cut between saw blade and rip fence |
1250 mm |
|
Tilting saw group |
0-45° |
|
Diameter of main saw blade |
300 mm |
|
Max cutting height (90°) |
80 mm |
|
Speed of main saw spindle |
4000/6000 r.p.m |
|
Main saw motor power |
5.5 kw |
|
Main spindle diameter |
30 mm |
|
Diameter of scoring saw blade |
120 mm |
|
Speed of scoring saw spindle |
8000 r.p.m |
|
Scoring saw motor power |
1.1 kw |
|
Scoring saw spindle diameter |
20 mm |
|
Weight |
750 KGS |
|
Overall dimension |
3250x3150x900 mm |
Feature：
1. Apply to processing all kinds of density boards, shaving boards, artificial board, ABS board, PVC board, organic glass plates and solid wood and others with wood structure and similar hardness.
2. Moveable table guide track is chromium steel bar structure, exact and durable
3. The sliding table is made of high strength extruded aluminum alloy, and it is high in strength and won’t bent
4. With oxidation treatment, the sliding table surface is beautiful and durable
5. The body is welded with heavy-duty steel and with special heat treatment, better stability and lower noise
